Yanmar Diesel Engines

Yanmar TF 70 H

Type

Single-cylinder diesel engine

Injection timing

bTDC 17°

Bore x stroke

78 x 80 mm

Displacement

0.382 L

Rated output

6.0 hp / 2400 rpm (4.5 kW)

1-hour rated output

7.0 hp / 2400 rpm (5.2 kW)

Maximum torque

2.48 kgf·m / 1800 rpm

Compression ratio

18.1

Fuel consumption

175 g/hp·h

Fuel tank capacity

7.1 L

Oil capacity

1.8 L

Cooling water capacity

8.0 L

Dimensions

607.5 x 311.5 x 469.0 mm

Weight

65.0 kg
